APC Easy 3S uninterruptible power supply (UPS) Double-conversion…
APC Easy 3S, Double-conversion (Online), 20 kVA, 20000 W, Pure sine, 304 V, 477 V
Click or hover over image to enlarge
Brand:APC
MPN:E3SUPS20KHB
Part #: E3SUPS20KHB
Form factor
Tower
Product colour
White
Display type
LED
International Protection (IP) code
IP20
Battery technology
Sealed Lead Acid (VRLA)
Battery voltage
220 V
Number of batteries supported
3
UPS topology
Double-conversion (Online)
Comsys Price
$13,847.14
Save $659.01 off RRP
Out of Stock
Contact us for ETA or alternatives
Free NZ deliveryover $150·Ships from Auckland, 1–3 days
Value Deal
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
APC EASY UPS 3S 20 KVA 400 V 3:3 UPS FOR INTERNAL BATTERIES
APC Easy 3S. UPS topology: Double-conversion (Online), Output power capacity: 20 kVA, Output power: 20000 W. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 220 V. Form factor: Tower, Product colour: White, Display type: LED. Compliance certificates: RoHS, Certification: CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH. Width: 380 mm, Depth: 928 mm, Height: 1400 mm
Key features
- UPS topology: Double-conversion (Online)
- Output power capacity: 20 kVA
- Output power: 20000 W
- Waveform: Pure sine
- Input operation voltage (min): 304 V
- Input operation voltage (max): 477 V
- Input frequency: 45/65 Hz
- Output operation voltage (min): 380 V
- Output operation voltage (max): 415 V
- Output frequency: 50/60 Hz
- Maximum current: 37 A
- Number of input phases: 3
- Number of output phases: 3
- Input power factor: 0.99
- Output voltage Total Harmonic Distortion (THD): 3%
- Input current Total Harmonic Distortion (THD): 3%
- SmartSlot: Yes
- SmartConnect port: No
- Battery technology: Sealed Lead Acid (VRLA)
- Battery voltage: 220 V
- Number of batteries supported: 3
- Form factor: Tower
- Product colour: White
- Display type: LED
- International Protection (IP) code: IP20
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -15 - 40 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Operating altitude: 0 - 999.9 m
+ 15 more — see the Specifications tab.
