APC Easy Rack PDU, Switched Metered Outlet, 0U, 1 Phase, 7.4kW,…

APC Easy Rack PDU, Switched Metered Outlet, 0U, 1 Phase, 7.4kW, 230V, 32A, (20) C13 and (4) C19 outlets, IEC60309 2P+E inlet, Metered, Switched, 0U, Single-phase, Vertical, Metal, Black

APC Easy PDU 2G Metered-by-Outlet with ZeroU

Click or hover over image to enlarge

Brand:APC
MPN:6181722

Part #: 6181722


Nominal input voltage

200 - 240 V

AC input frequency

50/60 Hz

Maximum current

32 A

Output voltage

200-240 V

Load capacity

7360 VA

Number of phases

1

Power protection features

Overload

PDU types

Metered, Switched


Returns & Warranty

Comsys Price

$2,604.74

Save $185.01 off RRP

Out of Stock

Contact us for ETA or alternatives

NZ-wide deliveryNZ Post rates·Ships from Auckland, 1–3 days
1
Afterpay

Four payments of $651.19 per fortnight

Value Deal

Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.

APC Easy PDU 2G Metered-by-Outlet with ZeroU

Easy rack PDU Metered-by-Outlet with Switching EPDU2132SMBO provides advanced power monitoring and control capabilities for individual outlets, empowering critical IT infrastructure. The Network Management Card NMC3 provides enhanced cybersecurity with secured interfaces and modified password policy. The rack PDU integrates with EcoStruxure IT through a Network Management Card (NMC3) and can be accessed and configured via Web, SNMP, and Command Line Interface. EPDU2132SMBO is designed for single phase applications of upto 7.4kw and industry standards of 1% metering accuracy. This comes with IEC 603093 32A 2P+E type inlet, Twenty IEC C13 and four IEC C19 type outlet sockets. It features an ultra-lightweight aluminum housing, offering up to 50% weight reduction, along with environmental monitoring and an all-new improved display module. Vertical mounting capabilities allow users to mount the units in a rack or enclosure in zero U space without expending valuable rack space This is designed to operate within a temperature range of -5°C to +50°C and is backed by a standard 2-year warranty. Remotely manage outlets so users can turn outlets off that are not in use (prevent overloads) or recycle power to locked-up equipment (minimize costly downtime and avoid travel time to equipment) The rack PDU supports daisy-chain of up to 4 PDUs on a single IP address, thereby reducing networking cost.

Key features

  • PDU types: Metered, Switched
  • Type: Single-phase
  • Rack capacity: 0U
  • Mounting: Vertical
  • Housing material: Metal
  • Product colour: Black
  • Display: LCD
  • AC outlets quantity: 20 AC outlet(s)
  • Power plug: IEC 60309
  • AC outlet types: C13 coupler
  • Cable length: 3 m
  • Nominal input voltage: 200 - 240 V
  • AC input frequency: 50/60 Hz
  • Maximum current: 32 A
  • Output voltage: 200-240 V
  • Load capacity: 7360 VA
  • Number of phases: 1
  • Power protection features: Overload
  • Operating temperature (T-T): -5 - 50 °C
  • Storage temperature (T-T): -25 - 65 °C
  • Operating relative humidity (H-H): 5 - 95%
  • Storage relative humidity (H-H): 5 - 95%
  • Operating altitude: 0 - 15000 m
  • Width: 55 mm
  • Depth: 56 mm
  • Height: 1800 mm
  • Weight: 7.42 kg
  • Package weight: 8.59 kg
  • Package width: 195 mm
  • Package depth: 130 mm

+ 1 more — see the Specifications tab.
