APC Easy PDU 2G Metered-by-Outlet with ZeroU

Easy PDU 2G Metered-by-Outlet with Switching ZeroU 16A 230V (20) C13 and (4) C19

  • Brand: APC
  • Category: UPS Systems
  • SKU: 6181720
  • MPN: EPDU2116SMBO

APC Easy Rack PDU, Switched Metered Outlet, 0U, 1 Phase, 3.7kW,…

APC Easy Rack PDU, Switched Metered Outlet, 0U, 1 Phase, 3.7kW, 230V, 16A, (20) C13 and (4) C19 outlets, IEC60309 2P+E inlet, Metered, Switched, 0U, Single-phase, Black, 24 AC outlet(s), C13 coupler, C19 coupler

APC Easy PDU 2G Metered-by-Outlet with ZeroU — APC — Power & UPS > UPS Systems

Click or hover over image to enlarge

Brand:APC
MPN:6181720

Part #: 6181720

Search this part on Google

Nominal input voltage

200 - 240 V

AC input frequency

50/60 Hz

Maximum current

16 A

Output voltage

230 V

Load capacity

3680 VA

Maximum power

3700 W

PDU types

Metered, Switched

Type

Single-phase


Returns & Warranty

Comsys Price

$2,135.54
On Sale

Save $318.01 off RRP

Available to Order

NZ-wide deliveryShips from Auckland · 1–3 days
1
Afterpay4 payments of $533.89
100% NZ Owned & OperatedCall 0800 664 554

Shipped NZ‑wide. Freight is calculated at checkout from live courier rates; delivery within Auckland is free on standard‑size items.

Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.

Add To Compare
We acceptVisaMastercardAmerican ExpressApple PayGoogle PayAfterpay
Afterpay — pay it in 4 interest-free instalments
Value Deal

Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.

APC Easy PDU 2G Metered-by-Outlet with ZeroU

Easy rack PDU Metered-by-Outlet with Switching EPDU2116SMBO provides advanced power monitoring and control capabilities for individual outlets, empowering critical IT infrastructure. The APC Network Management Card NMC3 provides enhanced cybersecurity with secured interfaces. The rack PDU integrates with EcoStruxure IT through a Network Management Card (NMC3) and can be accessed and configured via Web, SNMP, and Command Line Interface. EPDU2116SMBO is designed for single phase applications of upto 3.7kw and industry standards of 1% metering accuracy. This comes with IEC 60309 16A 2P+E type inlet, Twenty IEC C13 and four IEC C19 type outlet sockets. It features an ultra-lightweight aluminum housing, offering up to 50% weight reduction, along with environmental monitoring and an all-new improved display module. Vertical mounting capabilities allow users to mount the units in a rack or enclosure in zero U space without expending valuable rack space This is designed to operate within a temperature range of -5°C to +50°C and is backed by a standard 2-year warranty. Remotely manage outlets so users can turn outlets off that are not in use (prevent overloads) or recycle power to locked-up equipment (minimize costly downtime and avoid travel time to equipment) The rack PDU supports daisy-chain of up to 4 PDUs on a single IP address, thereby reducing networking cost.

Key features

  • PDU types: Metered, Switched
  • Type: Single-phase
  • Rack capacity: 0U
  • Product colour: Black
  • AC outlets quantity: 24 AC outlet(s)
  • Power plug: IEC 60309
  • AC outlet types: C13 coupler, C19 coupler
  • Ethernet LAN (RJ-45) ports: 1
  • USB ports quantity: 1
  • Cable length: 3 m
  • Nominal input voltage: 200 - 240 V
  • AC input frequency: 50/60 Hz
  • Maximum current: 16 A
  • Output voltage: 230 V
  • Load capacity: 3680 VA
  • Maximum power: 3700 W
  • Operating temperature (T-T): -5 - 50 °C
  • Storage temperature (T-T): -25 - 65 °C
  • Operating relative humidity (H-H): 5 - 95%
  • Storage relative humidity (H-H): 5 - 95%
  • Width: 55 mm
  • Depth: 56 mm
  • Height: 1800 mm
  • Weight: 6.67 kg
  • Package weight: 7.84 kg
  • Package width: 195 mm
  • Package depth: 130 mm
  • Package height: 2030 mm
