Allied Telesis AT-IE048-480-20 uninterruptible power supply (UPS)…
Allied Telesis AT-IE048-480-20, 480 W, 90 V, 350 V, 50/60 Hz, 48 V, 15 A
Click or hover over image to enlarge
Brand:ALLIED TELESIS
MPN:5232214
Part #: 5232214
Form factor
Tower
Housing material
Metal
Cooling type
Active
Product colour
White
LED indicators
Alarm, Status
Output power
480 W
Input operation voltage (min)
90 V
Input operation voltage (max)
350 V
Comsys Price
$679.64
Save $59.00 off RRP
Out of Stock
Contact us for ETA or alternatives
Free NZ deliveryover $150·Ships from Auckland, 1–3 days
Four payments of $169.91 per fortnight
Value Deal
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
ALLIED TELESIS 48V 480W DIN RAIL POWER SUPPLY
The ruggedized IE048-480 industrial power supply is a functional accessory for Allied Telesis products to build a solution suitable for Smart Cities (e.g. Surveillance & Security), Industrial Ethernet, Transportation or any application requiring systems that function in harsh environment with extended operating temperature.
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electromagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electromagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
Key features
- Output power: 480 W
- Input operation voltage (min): 90 V
- Input operation voltage (max): 350 V
- Input frequency: 50/60 Hz
- Output operation voltage (max): 48 V
- Maximum current: 15 A
- Efficiency: 94%
- Power factor: 0.98
- Power protection features: Over current, Over voltage, Overheating
- Form factor: Tower
- Housing material: Metal
- Cooling type: Active
- Product colour: White
- LED indicators: Alarm, Status
- Operating temperature (T-T): -20 - 70 °C
- Storage temperature (T-T): -40 - 85 °C
- Operating relative humidity (H-H): 20 - 90%
- Storage relative humidity (H-H): 20 - 90%
- Compliance certificates: RoHS, WEEE
- Width: 70 mm
- Depth: 117 mm
- Height: 124 mm
- Weight: 1.2 kg
- Export Control Classification Number (ECCN): 5A992C
- Harmonized System (HS) code: 8504.40.8500
- Nominal output voltage: 48 V
- Nominal input voltage: 90 - 264; 98 - 350 V
