StarTech.com 4 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane…
StarTech.com 4 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD, Black, Aluminium, 1 fan(s), 7 cm, 6 Gbit/s, Activity, Power
Click or hover over image to enlarge
Brand:STARTECH
MPN:HSB4SATSASBA
Part #: HSB4SATSASBA
Product colour
Black
Material
Aluminium
Hot-swap
Yes
Number of fans
1 fan(s)
Fan diameter
7 cm
Data transfer rate
6 Gbit/s
LED indicators
Activity, Power
Key lock
Yes
Comsys Price
$248.39
Save $42.30 off RRP
In Stock
6 units available
Free NZ deliveryover $150·Ships from Auckland, 1–3 days
Four payments of $62.10 per fortnight
Value Deal
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
STARTECH.COM 4 BAY TRAYLESS HOT SWAP 3.5" SATA HDD MOBILE RACK BACKPLANE 2 YR
Connect and hot swap four 3.5in SATA III or SAS II hard drives to your computer system in three 5.25” bays, with support for transfer speeds up to 6 Gbps
The HSB4SATSASBA Removable 4-drive Backplane makes inserting and removing drives fast and easy, by turning three 5.25" bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD).
For added versatility, the hot swap bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal solution for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides drive cooling with a built-in fan and excellent heat dissipation with a vented aluminum enclosure.
The HSB4SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
The HSB4SATSASBA Removable 4-drive Backplane makes inserting and removing drives fast and easy, by turning three 5.25" bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD).
For added versatility, the hot swap bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal solution for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides drive cooling with a built-in fan and excellent heat dissipation with a vented aluminum enclosure.
The HSB4SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Key features
- Product colour: Black
- Material: Aluminium
- Hot-swap: Yes
- Number of fans: 1 fan(s)
- Fan diameter: 7 cm
- Data transfer rate: 6 Gbit/s
- LED indicators: Activity, Power
- Key lock: Yes
- Certification: CE, FCC
- External SATA ports quantity: 4
- Width: 145 mm
- Depth: 197 mm
- Height: 124 mm
- Weight: 1.3 kg
- Package width: 254 mm
- Package depth: 164 mm
- Package height: 180 mm
- Package weight: 1.59 kg
- Cables included: SATA
- Screws included: Yes
- Manual: Yes
- Storage temperature (T-T): -20 - 65 °C
- Operating temperature (T-T): 0 - 55 °C
- Operating relative humidity (H-H): 5 - 85%
- Compliance certificates: RoHS
- Products per master (outer) case: 6 pc(s)
- Master (outer) case width: 385 mm
- Master (outer) case length: 516 mm
- Master (outer) case height: 281 mm
- Harmonized System (HS) code: 84733080
