NETGEAR M4300-24X Managed L3 10G Ethernet (100/1000/10000) Black

NETGEAR M4300-24X, Managed, L3, 10G Ethernet (100/1000/10000), Rack mounting

NETGEAR XSM4324CS-100AJS AV Line 24-Port 10GigE Managed Network Switch with SFP+

Click or hover over image to enlarge

Brand:NETGEAR
MPN:XSM4324CS-100AJS

Part #: XSM4324CS-100AJS


AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Power consumption (max)

125 W

Rack mounting

Yes

Stackable

Yes

Product colour

Black

Housing material

Metal

Reset button

Yes


Returns & Warranty

Comsys Price

$9,627.79

Save $1,596.01 off RRP

Out of Stock

Contact us for ETA or alternatives

Free NZ deliveryover $150·Ships from Auckland, 1–3 days
1
Add To Compare
Value Deal

Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.

NETGEAR XSM4324CS-100AJS AV Line 24-Port 10GigE Managed Network Switch with SFP+

NETGEAR ProSAFE M4300-24X Stackable L3 Managed Switch comes with 24-port 10GBASE-T, 4-port shared 10GBASE-X SFP+ and 480Gbps fabric in a half-width form factor. All 24 ports are 1G backward compatible for progressive transition to 10G speeds. M4300-24X is line-rate with 480Gbps fabric for spine and leaf stacking architectures. M4300 Switch Series delivers L2/L3/L4 and IPv4/IPv6 rich services for mid-enterprise edge and SMB core with unrivalled ease of use: 10 Gigabit models can seamlessly stack with 1 Gigabit models within the series. Non-stop forwarding (NSF) virtual chassis architectures provide advanced High Availability (HA) with hitless failover, that is, distributed link aggregation allows for load balancing and virtually zero downtime. M4300 is ideal for server aggregation with Auto-iSCSI prioritization: two half-width M4300 switches can be installed in a single rack space for redundant Top of Rack installations. Layer 3 feature set includes static and policy-based routing, RIP, VRRP, OSPF, and PIM dynamic routing – as standard. The NETGEAR M4300 Switch Series is also ready for the future, with Software-defined Network (SDN) and OpenFlow 1.3 enabled for your network.

Key features

  • Switch type: Managed
  • Switch layer: L3
  • Quality of Service (QoS) support: Yes
  • ARP inspection: Yes
  • System event log: Yes
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
  • SFP+ module slots quantity: 4
  • Console port: RJ-45
  • USB 2.0 ports quantity: 2
  • Networking standards: IEEE 802.1AX, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3u, IEEE 802.3z
  • 10G support: Yes
  • Port mirroring: Yes
  • Flow control support: Yes
  • Link aggregation: Yes
  • Broadcast storm control: Yes
  • Auto MDI/MDI-X: Yes
  • Spanning tree protocol: Yes
  • Auto-negotiation: Yes
  • VLAN support: Yes
  • Virtual LAN features: Private VLAN, Voice VLAN, Tagged VLAN
  • Number of VLANs: 4000
  • Switching capacity: 480 Gbit/s
  • Forwarding rate: 357 Mpps
  • MAC address table: 16000 entries
  • Store-and-forward: Yes
  • Latency (1 Gbps): 1.827 µs
  • Latency (10 Gbps): 2.728 µs
  • Jumbo frames support: Yes
  • Jumbo frames: 9216

+ 22 more — see the Specifications tab.
