Kramer VS-411XS 4K HDR HDMI Auto Switcher
- Brand: Kramer
- Category: HDMI / Display Cables
- SKU: 485464
- MPN: VS-411XS
Kramer VS-411XS 4K HDR HDMI Auto Switcher
Kramer VS-411XS 4 x 1 4K HDR HDMI Intelligent Auto Switcher VS-411XS is an intelligent 4x1 automatic switcher for 4K HDR, HDMI video signals. VS-411XS offers an intelligent switching experience with built-in Maestro room control and the standard priority / last-connected switching function based on active video signal detection. Key Features 4x1 Plug & Play Switcher Powerful Built-in Maestro Room Control Intelligent IP-driven Control Gateway Up to 4K@60Hz (4:4:4) Resolution Technical Specifications INPUTS 4 HDMI On a female HDMI connector OUTPUTS 1 HDMI On a female HDMI connector 1 Balanced Stereo Audio On 5-pin terminal block connector PORTS RS-232 On a 3-pin terminal block connector Remote Contact Closure On an 8-pin terminal block connector Ethernet On an RJ-45 connector VIDEO Max Data Rate 17.82GBPS (5.94Gbps per graphic channel) Max Resolution 4K@60 (4:4:4) Compliance HDR10 as specified in HDMI 2.0, HDCP 2.2 POWER Source 5V DC, 4A Consumption 810mA USER INTERFACE Controls Inputs selection, volume, and mute buttons, DIP-switches for configuring switching policy and audio de-embedding source, embedded web pages via IP ENCLOSURE Size DemiTOOLS Type Aluminum Cooling Convection ventilation ENVIRONMENTAL CONDITIONS Operating Temperature 0 to +40C (32 to 104F) Storage Temperature -40 to +70C (-40 to 158F) Humidity 10% to 90%, RHL non-condensing REGULATORY COMPLIANCE (STANDARDS COMPLIANCE) Health, Safety, Environmental RoHs, WEEE, CE PRODUCT DIMENSIONS 19.05cm x 5.96cm x 2.74cm (7.50” x 2.35” x 1.08”) W, D, H PRODUCT WEIGHT 0.3kg (0.7lbs) approx. SHIPPING DIMENSIONS 34.50cm x 16.50cm x 5.20cm (13.58” x 6.50” x 2.05”) W, D, H SHIPPING WEIGHT 0.8kg (1.7lbs) approx.
