ATEN 2A-136G network transceiver module Fiber optic 1250 Mbit/s SFP…
ATEN 2A-136G, Fiber optic, 1250 Mbit/s, SFP, 550 m, 1300 nm, Blue, Metallic
Click or hover over image to enlarge
Brand:ATEN
MPN:2A-136G
Part #: 2A-136G
Product colour
Blue, Metallic
SFP transceiver type
Fiber optic
Maximum data transfer rate
1250 Mbit/s
Interface type
SFP
Single-mode fiber (SMF) supported
Yes
Multi-mode fiber (MMF) supported
Yes
Maximum transfer distance
550 m
Wavelength
1300 nm
Comsys Price
$178.24
Save $16.36 off RRP
Out of Stock
Contact us for ETA or alternatives
NZ-wide deliveryNZ Post rates·Ships from Auckland, 1–3 days
Four payments of $44.56 per fortnight
Value Deal
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
ATEN MULTI-MODE MODULE 550M SFP OPTICAL MODULE FOR KE89XX/KE99XX SERIES
The 2A-136G 1.25G Multi-Mode/550M Fiber SFP Module provides 1 GbE connectivity up to 550 meters. The transceiver can be installed in both transmitters and receivers. As a hotpluggable module with a standard duplex connector for fiber communications, the 2A-136G works with multi-mode-fiber (MMF) connections and operates at a nominal wavelength of 850 nm which makes it a cost-effective and high performance transceiver.
Key features
- SFP transceiver type: Fiber optic
- Maximum data transfer rate: 1250 Mbit/s
- Interface type: SFP
- Single-mode fiber (SMF) supported: Yes
- Multi-mode fiber (MMF) supported: Yes
- Maximum transfer distance: 550 m
- Wavelength: 1300 nm
- Digital Diagnostics Monitoring (DDM): Yes
- Product colour: Blue, Metallic
- Compliance certificates: RoHS
- Operating temperature (T-T): 0 - 70 °C
- Storage temperature (T-T): -40 - 85 °C
- Width: 146 mm
- Depth: 55.9 mm
- Height: 13 mm
- Weight: 20 g
- Harmonized System (HS) code: 85369010
