ATEN KVM ADAPTER MODULE WITH USB, PS/2, AND RS-232 LOCAL CONSOLE
Networking > Network Accessories
- Brand: ATEN
- Category: Networking
- SKU: KA7174-AX-U
- MPN: KA7174-AX-U
ATEN KA7174-AX-U KVM switch Black
ATEN KA7174-AX-U, 1920 x 1200 pixels, Ethernet LAN, WUXGA, 1.75 W, Black
Click or hover over image to enlarge
Input voltage
5 V
Power consumption (typical)
1.75 W
Rack mounting
No
Product colour
Black
Housing material
Metal
LED indicators
Yes
Push button
Yes
Built-in display
No
Comsys Price
Save $167.47 off RRP
Available to Order
4 payments of $245.81Shipped NZ‑wide. Freight is calculated at checkout from live courier rates; delivery within Auckland is free on standard‑size items.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 68 Plunket Avenue, Papatoetoe, Auckland 2104
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
ATEN KVM ADAPTER MODULE WITH USB, PS/2, AND RS-232 LOCAL CONSOLE
KA7174 KVM Adapter Module is designed to provide a convenient local console connection in a KVM over IP switch or matrix KVM installation. KA7174 allows a PS/2, USB, or RS-232 server to be connected to an ATEN KVM over IP switch via Cat 5e / 6 cable while providing an extra local console connection supporting USB or PS/2 keyboard and mouse, monitor, and / or RS-232 touch panel for convenient local operation. In addition, the KA7174 also features Privileged Console Control function with OSD tag notifications indicating denial of access to the local or remote users when configured as such.
Key features
- Serial port type: DE-9 (DB-9)
- Serial ports quantity: 2
- DC-in jack: Yes
- Ethernet LAN: Yes
- Ethernet LAN (RJ-45) ports: 1
- HD type: WUXGA
- Maximum resolution: 1920 x 1200 pixels
- Video bandwidth: 60 Hz
- Rack mounting: No
- Product colour: Black
- Housing material: Metal
- LED indicators: Yes
- Push button: Yes
- Built-in display: No
- Input voltage: 5 V
- Power consumption (typical): 1.75 W
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Width: 86.4 mm
- Depth: 203 mm
- Height: 25 mm
- Weight: 490 g
Inc GST
$983.24
