ATEN 8-Port USB - PS/2 VGA KVM Switch
ATEN 8-Port USB - PS/2 VGA KVM Switch, 2048 x 1536 pixels, QXGA, Rack mounting, 5 W, 1U, Black
Click or hover over image to enlarge
Brand:ATEN
MPN:CS1308-AT-U
Part #: CS1308-AT-U
Power source
DC
Input voltage
5.3 V
Power consumption (typical)
5 W
Rack mounting
Yes
Rack capacity
1U
Product colour
Black
Housing material
Metal
Cascadable
Yes
Comsys Price
$489.89
Save $76.00 off RRP
Only 2 left in stock
Order soon to avoid backorder
Free NZ deliveryover $150·Ships from Auckland, 1–3 days
Four payments of $122.47 per fortnight
Value Deal
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
ATEN 8 PORT VGA KVMP SWITCH
The CS1308 is a 8-Port USB-PS/2 KVM switch (Dual Interface). You're able to control up to 64 Computers from a single console (keyboard, mouse, and monitor).
8 additional switches can be cascaded (2-Level) that's why the total number of connected computers can be up to 64 computers, that can be controlled from a single keyboard-monitor-mouse console. The switch supports both USB and PS/2 connections for the console and Computer/PC/Server (Dual Interface.
1x CS1308 KVM Switch with Rack Mount Kit
1x LIN5-27X6-U21G Console cable
1x Firmware Upgrade cable
1x Foot Pad set (4 pads)
1x 0AD8-1605-24M1 Power Adapter
1x User Instructions
8 additional switches can be cascaded (2-Level) that's why the total number of connected computers can be up to 64 computers, that can be controlled from a single keyboard-monitor-mouse console. The switch supports both USB and PS/2 connections for the console and Computer/PC/Server (Dual Interface.
1x CS1308 KVM Switch with Rack Mount Kit
1x LIN5-27X6-U21G Console cable
1x Firmware Upgrade cable
1x Foot Pad set (4 pads)
1x 0AD8-1605-24M1 Power Adapter
1x User Instructions
Key features
- Number of computers controlled: 64
- Keyboard port type: USB, PS/2
- Mouse port type: USB, PS/2
- Video port type: VGA
- VGA (D-Sub) ports quantity: 8
- Console ports: VGA (D-Sub)
- DC-in jack: Yes
- HD type: QXGA
- Maximum resolution: 2048 x 1536 pixels
- Scan interval: 1,255 s
- DDC2B support: Yes
- Firmware upgradeable: Yes
- Rack mounting: Yes
- Rack capacity: 1U
- Product colour: Black
- Housing material: Metal
- Cascadable: Yes
- Push button: Yes
- Hot keys: Yes
- Built-in display: No
- Power source: DC
- Input voltage: 5.3 V
- Power consumption (typical): 5 W
- Windows operating systems supported: Yes
- Linux operating systems supported: Yes
- Mac operating systems supported: Yes
- Other operating systems supported: Yes
- Compliance certificates: RoHS
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
+ 20 more — see the Specifications tab.
