APC WW 10KVA Isolation Transformer
APC WW 10KVA Isolation Transformer, Black, Hard Wire 3-wire (2PH + G), Hard Wire 3 wire (1PH+N+G), 1x Hard Wire 3-wire (H N + G), 230 V, 230 V, 10000 VA
Click or hover over image to enlarge
Part #: 2408546
Nominal input voltage
230 V
Nominal output voltage
230 V
Load capacity
10000 VA
Maximum input current per phase
60 A
Maximum total current draw per phase
60 A
Product colour
Black
Certification
C-tick,CE,CSA,EN 55022 Class A,EN 55024,EN 61000-3-2,EN 61000-3-3,GOST,UL Listed,VDE
Total carbon footprint (kg of CO2e)
10587.81
Comsys Price
Save $498.01 off RRP
Out of Stock
Contact us for ETA or alternatives
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
APC WW 10KVA Isolation Transformer
Key features
- Product colour: Black
- Input connection type: Hard Wire 3-wire (2PH + G), Hard Wire 3 wire (1PH+N+G)
- Output connections: 1x Hard Wire 3-wire (H N + G)
- Nominal input voltage: 230 V
- Nominal output voltage: 230 V
- Load capacity: 10000 VA
- Maximum input current per phase: 60 A
- Maximum total current draw per phase: 60 A
- Certification: C-tick,CE,CSA,EN 55022 Class A,EN 55024,EN 61000-3-2,EN 61000-3-3,GOST,UL Listed,VDE
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -25 - 65 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Width: 432 mm
- Depth: 749 mm
- Height: 175 mm
- Weight: 100 kg
- Total carbon footprint (kg of CO2e): 10587.81
Inc GST
$7,218.54
