Allied Telesis X530L-18GHXM Managed L3 Fast Ethernet (10/100) Power…
Allied Telesis X530L-18GHXM, Managed, L3, Fast Ethernet (10/100), Power over Ethernet (PoE), Rack mounting
Click or hover over image to enlarge
Part #: 5938554
Power source
AC
Power consumption (max)
970 W
Rack mounting
Yes
Stackable
Yes
Networking standards
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
Yes
VLAN support
Yes
DHCP features
DHCPv6 client, DHCPv6 relay, DHCPv6 server
Comsys Price
Save $598.00 off RRP
Out of Stock
Contact us for ETA or alternatives
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
ALLIED TELESIS L3 Stackable Switch 16x 100M/1/2.5/5G-T
The Allied Telesis x530L Series stackable Layer 3 switches feature high capacity, resiliency and easy management. With both Multi-Gigabit and high port density models, plus Power over Ethernet, they are the ideal choice for network access applications.
Key features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Basic switching RJ-45 Ethernet ports quantity: 16
- Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
- Installed SFP+ modules quantity: 2
- Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support: Yes
- VLAN support: Yes
- Switching capacity: 200 Gbit/s
- Forwarding rate: 148.8 Mpps
- MAC address table: 16000 entries
- Latency (10-100 Mbps): 8.35 µs
- Latency (1 Gbps): 7.96 µs
- Latency (10 Gbps): 2.56 µs
- DHCP features: DHCPv6 client, DHCPv6 relay, DHCPv6 server
- Security algorithms: 3DES, AES, EAP, HTTPS, MD5, PEAP, SHA-1, SHA-2, SHA-256, SHA-384, SHA-512, TLS, TTLS
- SSH/SSL support: Yes
- Authentication type: IEEE 802.1x, RADIUS
- Routing protocols: BGP, BGP4, OSPF, OSPFv2, OSPFv3, RIP, RIP-2
- Rack mounting: Yes
- Stackable: Yes
- Noise level: 42 dB
- Power source: AC
- Power consumption (max): 970 W
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 16
- Total Power over Ethernet (PoE) budget: 720 W
- Heat dissipation: 3317 BTU/h
- Width: 441 mm
+ 7 more — see the Specifications tab.
Inc GST
$8,601.99
